• High resolution due to droplet size, up to 720 x 2400 dpi.
• Recirculation system: Avoids clogging of white ink ensuring fluidity and
normal operation.
• Ink stiring system: prevents white ink sedimentation.
• Polyamide shaker system for greater adherence and utility.
• Motor (Take Up) to pick up the printed material.
• Continuous ink supply system, ink tanks and cartridges included without chip
blocker.
• Ink alarm system: Ink level alarm for each color channel.
• Adjustable drying temp depending on print speed.
• Robust Pinch Roller system: Holds down media that is not straight or comes
loose, preventing misalignment during printing.
TECHNICAL SPECIFICATIONS
Printing width: 24 inch / 60cm
Number of heads: 3
Color channels: CMYK + RGBO + FLUOR INK
Printer size: 74” x 71” x 59”
Printing speed:
6 Pass: Up to 28 linear ft/h
8 Pass: Up to 21 linear ft/h
Software Rip: Flexiprint ESS V22
File compatibility: PDF, JPG, TIFF, etc.
Dimensions: 67 in x 34 in x 56 in
Voltage: 220V
Printer power: 1800 W
Weight: 562 Lb / 254 Kg
GENERAL:
Software RIP: Included *
Humidity: 45 / 75%
Temp: 65° F – 83° F
POWER CONSUMPTION:
Voltage: 220 VAC
Power: 4.2 Kw
PRINTER DRYING SYSTEM:
Front and rear heater
